LSF Series Safety Lock

Anti-Tilt Type Safety Lock (LSF)
 Safety Standard: EN1808
 The anti-Tilt safety lock is automatically tripped when the angle of the rope or the platform exceeds 3-10°.
 The integrated clamping jaw mechanism holds the rope and immediately stops the movement of the system.
 It is designed for long platform with end stirrup.

Categories
Model LSF308 LSF309 LSF310
Rated Load 630kg 800kg 1000kg
Wire Rope Diameter 8.3mm 9.1mm 10.2mm
Locking Distance ≤200mm
Cable Locking Angle 3°-10
